Triton RL2000
Triton 9100 has a patented cabinet design that increases integrity
and security while making the unit easier and quicker to install.
Contact us to buy the 9100 ATM.
TRITON
RL200 Full Brochure
Screen
5.7" VGA Color Display
8" VGA Color Display Optional
Printer
60 mm Thermal Printer
80 mm Thermal Printer (Optional)
Topper
Mid-Topper
High-Topper (Optional)
Lock Options
Manual Lock
Electronic Lock (Optional)
Kaba® Mas Cencon 2000 Lock (Optional)
Communicatons
56k Baud USB Modem
TCP/IP
Wireless Capable
Compliance
Americans with Disabilities Act (ADA)
Audio Compliance for Visually Impaired
Triple DES Compliant
UK Accessibility Guidelines (DDA)
California Access Compliance, Title 24
Canadian Barrier Free Design (CBFD)
PCI Compliant Encrypting PIN Pad with Plastic Keys
PCI Compliant Encrypting PIN Pad with Metal Keys (Optional)
RKT Up-gradable Encrypting PIN Pad (Optional)
Dimensions
Length - 22.1” (562 mm)
Width - 16” (405 mm)
Height - 49.5” (1257 mm)
175 lbs (79 kg) Varies with Options
Triton RL5000
With a stunning 10.4-inch LCD screen, the RL5000 allows for a remarkable array of colorful, branded content. Logos, photos, and custom graphics of all kinds are quickly and easily integrated, using the simple-to-operate PC-based interface. At the heart of this almost endlessly configurable system is the user-friendly Microsoft® Windows® CE 5.0 operating system, powered by Triton’s X2 technology and a 32-Bit processor. Contact us to buy the RL5000 ATM.
TRITON RL 5000 Full BrochureScreen
10.4" VGA Color Display Screen
Communication
56k Baud USB Modem/Dial Up
TCP/IP
Wireless (Optional)
Security
Electronic Lock
Kaba® Mas Cencon 2000 Lock (Optional)
Compliance
Americans with Disabilities Act (ADA)
Audio Compliance for Visually Impaired
Triple DES Compliant
UK Accessibility Guidelines (DDA)
California Access Compliance, Title 24
Canadian Barrier Free Design (CBFD)
PCI Compliant Encrypting PIN Pad with Metal Keys
PCI Compliant Encrypting PIN Pad with Metal Case & Keys (Optional)
RKT Upgradable Encrypting PIN Pad
Signage
Mid-Topper
High-Topper (Optional)
Power Supply
AC 110~230V, 50~60Hz
Dimension and Weight
Length: 25.6” (650 mm)
Width: 16.9” (429 mm)
Height: 54.3” (1390 mm)
Business Hours Cabinet — 172 lbs (78 kg)
Level 1 Vault — 600 lbs (275 kg)
Triton RT2000
The extremely reliable and affordable Triton RT2000 gives merchants a low-cost, easy to service, 24-hour alternative to more expensive through-the-wall ATMs for sale.
The RT2000 boasts viewing options not available elsewhere in the market. Bigger
display options and the ability to keep sunlight at bay make this
ATM the ideal choice for outdoor placement. The Triton RT2000 is
easy to install and maintain. And best of all, its low cost and
reliability mean your high-traffic ATM location can finally become
a high-profit ATM location. Contact us
to buy the RL5000 ATM.
Screen
10.4" VGA Color Display
Sunlight Viewable Display (Optional)
Rear Service Panel with 5.7”
Touch Screen Monitor
Communication
56k Baud USB Modem/Dial Up
TCP/IP
Wireless Cabable
Security
Electronic Lock
Kaba® Mas Cencon 2000 Lock (Optional)
Camera Port
Compliance
Americans with Disabilities Act (ADA)
Audio Compliance for Visually Impaired
Triple DES Compliant
UK Accessibility Guidelines (DDA)
California Access Compliance, Title 24
Canadian Barrier Free Design (CBFD)
PCI Compliant Encrypting PIN Pad with Plastic Keys
PCI Compliant Encrypting PIN Pad with Metal Keys (Optional)
PCI Compliant Encrypting PIN Pad with Metal Keys & Case (Optional)
RKT Upgradable Encrypting PIN Pad (Optional)
Signage
LED Backlit Signage
Card Reader
Dip-Style Card Reader
Dip-Style EMV Smart Card Reader (Optional)
Motorized EMV Card Reader (Optional)
Power Supply
AC 110~230V, 50~60Hz
Dimension and Weight
Length — 29.7" (754 mm)
Width — 20.5” (521 mm)
Height — 63.6” (1,615 mm)
Business Hours Cabinet — 275 lbs (125 kg)
Level 1 Vault — 824 lbs (374 kg)
